دوربین مداربسته مخفی IPC-HUM8441

توضیحات

دوربین مداربسته مخفی IPC-HUM8441

دوربین مداربسته مخفی IPC-HUM8441 دوربین کاملا مخفی برای زمان هایی که نیاز است دوربین های مداربسته دیده نشوند این دوربین از کیفیت ۴ مگاپیکسل بهره میبرد که باعث میشود این دوربین از قدرتی تصویری بالایی بهره ببرد.

این دوربین با قابلیت یادگیری بالای الگوریتم هوش مصنوعی استفاده میکند ک میتواند به کاربران امکان را بدهد تا در صورتت نیاز فرمان های خاصی را به آن بدهند.

همچنین این دوربین دارای قابلیت تشخیص چهره و حسگر حرکتی میباشد که به این معناست که ایم دوربین کوچک از قدرت بالایی مانند دوربین بالت و دام بهره مند باشد.

میتواند از طریق سایت و تماس این دوربین جذاب را سفارش دهید. جهت کسب اطلاعات بیشتر درباره شرکت به سایت ارشیا الکترونیک کویر مراجعه فرمایید.



کاربرد

دوربین مداربسته مخفی IPC-HUM8441

Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.
WDR
With advanced Wide Dynamic Range (WDR) technology, Dahua network camera provides clear details in the environment of strong brightness contrast. The bright and dark area can get clear video even in high brightness environment or with backlight shadow.
Perimeter Protection
With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.
Face Detection
Dahua Face Detection technology can detect the face in the image. With deep learning algorithm, the technology supports detecting, tracking, capturing and selecting the best face image, and then outputs face snapshot.
Face Attributes
With deep learning algorithm, the network camera can recognize face attributes, such as gender, age, expression, glasses, mouth mask, and beard.
Cyber Security
Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera’s defense against external cyber threats and prevent malicious programs from comprising the device.



مشخصات

دوربین مداربسته مخفی IPC-HUM8441

Camera
Image Sensor
۱/۲.۷” CMOS
Max. Resolution
۲۶۸۸ (H) × ۱۵۲۰(V)
ROM
۱۲۸ MB
RAM
۱ GB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–۱/۱۰۰,۰۰۰ s
Min. Illumination
۰.۰۰۵ Lux@F2.0 (Color,30 IRE)
۰.۰۰۰۵ Lux@F2.0 (B/W,30 IRE)
S/N Ratio
＞۵۶ dB
Lens
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
۲.۸ mm
Max. Aperture
۲.۸ mm: F2.0
Field of View
Horizontal: 101°;
Vertical: 57°;
Diagonal: 115°
Iris Control
Fixed
Close Focus Distance
۰.۸ m
DORI Distance
Len
Detect
Observe
Recognize
Identify
IPC-
HUM8441-
L1
۶۱ m
(۲۰۰.۱ ft)
۲۴.۴ m
(۸۰.۱ ft)
۱۲.۲ m
(۴۰.۰ ft)
۶.۱ m
(۲۰.۰ ft)
Intelligence
IVS (Perimeter Protection)
Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
Face Detection
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attribute extraction including 6 attributes (gender, age, glasses, expressions, mask and beard) and 8 expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear); face snapshot set as face or one-inch photo; 3 snapshot strategies (real-time snapshot, optimization snapshot, and quality priority); face angle filter; optimization time setting
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+
Smart H.264+
Video Frame Rate
Main stream: 2688 × ۱۵۲۰ @۲۵/۳۰ fps
Sub stream: 704 × ۵۷۶ @۲۵ fps; 704 × ۴۸۰ @۳۰ fps
Third stream: 1920 × ۱۰۸۰ @۲۵/۳۰ fps
Stream Capability
۳ streams
Resolution
۴M (2688 × ۱۵۲۰); ۳.۶M (2560 × ۱۴۴۰); ۳M (2048 × ۱۵۳۶);۱۰۸۰p (1920 × ۱۰۸۰); ۹۶۰p (1280 × ۹۶۰); ۷۲۰p (1280 × ۷۲۰); D1 (704 × ۵۷۶/۷۰۴ × ۴۸۰); CIF (352 × ۲۸۸/۳۵۲ × ۲۴۰); VGA (640 × ۴۸۰)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 kbps–۲۰۴۸۰ kbps
H.265: 3 kbps–۲۰۴۸۰ kbps
Day/Night
Color/B/W
BLC
Yes
HLC
Yes
WDR
۱۲۰ dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Manual; auto
Noise Reduction
۳D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Defog
Yes
Image Rotation
۰°/۹۰°/۱۸۰°/۲۷۰° (support 90°/۲۷۰° with 1080p resolution and lower)
Mirror
Yes
Privacy Masking
۴ areas
Audio
Audio Compression
G.711a; G.711Mu; PCM; G.726; G.723
Alarm
Alarm Event
No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, tripwire, intrusion, fast moving, missing object, abandoned object, parking detection, loitering detection, people gathering; scene changing, audio detection, voltage detection, external alarm, face detection , and security exception
Network
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Network Protocol
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
۲۰ (Total bandwidth: 64 M)
Storage
FTP; SFTP; Micro SD card (Support max. 256 G); NAS
Browser
IE: IE8, IE9, and IE11
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Client
IOS; Android
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgradeCamera
Image Sensor
۱/۲.۷” CMOS
Max. Resolution
۲۶۸۸ (H) × ۱۵۲۰(V)
ROM
۱۲۸ MB
RAM
۱ GB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual 1/3 s–۱/۱۰۰,۰۰۰ s
Min. Illumination
۰.۰۰۵ Lux@F2.0 (Color,30 IRE)
۰.۰۰۰۵ Lux@F2.0 (B/W,30 IRE)
S/N Ratio
＞۵۶ dB
Lens
Lens Type
Fixed-focal
Lens Mount
M12
Focal Length
۲.۸ mm
Max. Aperture
۲.۸ mm: F2.0
Field of View
Horizontal: 101°;
Vertical: 57°;
Diagonal: 115°
Iris Control
Fixed
Close Focus Distance
۰.۸ m
DORI Distance
Len
Detect
Observe
Recognize
Identify
IPC-
HUM8441-
L1
۶۱ m
(۲۰۰.۱ ft)
۲۴.۴ m
(۸۰.۱ ft)
۱۲.۲ m
(۴۰.۰ ft)
۶.۱ m
(۲۰.۰ ft)
Intelligence
IVS (Perimeter Protection)
Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection, people gathering, and parking detection
Face Detection
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attribute extraction including 6 attributes (gender, age, glasses, expressions, mask and beard) and 8 expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear); face snapshot set as face or one-inch photo; 3 snapshot strategies (real-time snapshot, optimization snapshot, and quality priority); face angle filter; optimization time setting
Smart Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart Codec
Smart H.265+
Smart H.264+
Video Frame Rate
Main stream: 2688 × ۱۵۲۰ @۲۵/۳۰ fps
Sub stream: 704 × ۵۷۶ @۲۵ fps; 704 × ۴۸۰ @۳۰ fps
Third stream: 1920 × ۱۰۸۰ @۲۵/۳۰ fps
Stream Capability
۳ streams
Resolution
۴M (2688 × ۱۵۲۰); ۳.۶M (2560 × ۱۴۴۰); ۳M (2048 × ۱۵۳۶);۱۰۸۰p (1920 × ۱۰۸۰); ۹۶۰p (1280 × ۹۶۰); ۷۲۰p (1280 × ۷۲۰); D1 (704 × ۵۷۶/۷۰۴ × ۴۸۰); CIF (352 × ۲۸۸/۳۵۲ × ۲۴۰); VGA (640 × ۴۸۰)
Bit Rate Control
CBR/VBR
Video Bit Rate
H.264: 3 kbps–۲۰۴۸۰ kbps
H.265: 3 kbps–۲۰۴۸۰ kbps
Day/Night
Color/B/W
BLC
Yes
HLC
Yes
WDR
۱۲۰ dB
Scene Self-adaptation (SSA)
Yes
White Balance
Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control
Manual; auto
Noise Reduction
۳D NR
Motion Detection
OFF/ON (4 areas, rectangular)
Region of Interest (RoI)
Yes (4 areas)
Defog
Yes
Image Rotation
۰°/۹۰°/۱۸۰°/۲۷۰° (support 90°/۲۷۰° with 1080p resolution and lower)
Mirror
Yes
Privacy Masking
۴ areas
Audio
Audio Compression
G.711a; G.711Mu; PCM; G.726; G.723
Alarm
Alarm Event
No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, tripwire, intrusion, fast moving, missing object, abandoned object, parking detection, loitering detection, people gathering; scene changing, audio detection, voltage detection, external alarm, face detection , and security exception
Network
Network Port
RJ-45 (10/100 Base-T)
SDK and API
Yes
Network Protocol
IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Interoperability
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec
User/Host
۲۰ (Total bandwidth: 64 M)
Storage
FTP; SFTP; Micro SD card (Support max. 256 G); NAS
Browser
IE: IE8, IE9, and IE11
Chrome
Firefox
Management Software
Smart PSS; DSS; DMSS
Mobile Client
IOS; Android
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
