دستگاه ضبط دیجیتال سری کوپر داهوا مدل XVR1B16H

XVR1B16H

16 Channel Penta-brid 4M-N/1080P Cooper 1U 1HDD Digital Video Recorder

  • H.265+/H.265 dual-stream video compression
  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs
  • Max 24 channels IP camera inputs, each channel up to 6MP; Max 96Mbps incoming bandwidth
  • Long transmission distance over coax cable
  • Supports 1 SATA HDD, up to 6TB
  • Smart Search and Intelligent Video System

مقایسه
دسته: ,

مشخصات سایت منبع

System
Main Processor Embedded Processor
Operating System Embedded LINUX
Video and Audio
Analog Camera Input ۱۶ Channel, BNC
HDCVI Camera ۵MP, 4MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps
AHD Camera ۵MP, 4MP, 1080p@25/30, 720p@25/30 fps
TVI Camera ۵MP, 4MP, 1080p@25/30, 720p@25/30 fps
CVBS Camera PAL/NTSC
IP Camera Input ۱۶+۸CH, each channel up to 6MP
Audio In/Out ۱/۱, RCA
Two-way Talk Reuse audio in/out, RCA
Recording
Video Compression H.265+/H.265/H.264+/H.264
Resolution ۵M-N, 4M-N, 1080p, 1080N, 720p, 960H, D1, CIF
Record Rate Main stream: 5M-N(1~10 fps), 4M-N/1080p(1~15 fps); 1080N/720p/960H/D1/CIF (1~25/30 fps)

Sub stream: D1/CIF(1~15 fps)
Video Bit Rate ۳۲ Kbps ~ 6144 Kbps Per Channel
Record Mode Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval ۱ ~ ۶۰ min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Audio Compression G.711A, G.711U, PCM
Audio Sample Rate ۸ KHz, 16 bit Per Channel
Audio Bit Rate ۶۴ Kbps Per Channel
Display
Interface ۱ HDMI ,1 VGA
Resolution HDMI: 3840 × ۲۱۶۰, ۲۵۶۰ × ۱۴۴۰, ۱۹۲۰ × ۱۰۸۰, ۱۲۸۰ × ۱۰۲۴, ۱۲۸۰ × ۷۲۰

VGA: ۱۹۲۰ × ۱۰۸۰, ۱۲۸۰ × ۱۰۲۴, ۱۲۸۰ × ۷۲۰
Multi-screen Display When IP extension mode not enabled: ۱/۴/۸/۹/۱۶

When IP extension mode enabled: ۱/۴/۸/۹/۱۶/۲۵
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Network
Interface ۱ RJ-45 Port (1000M)
Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Max. User Access ۱۲۸ users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 16.12, CGI Conformant
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × ۱۸), Video Loss, Tampering and Diagnosis
Alarm input N/A
Relay Output N/A
Playback and Backup
Playback ۱/۴/۹/۱۶
Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Storage
Internal HDD ۱ SATA Port, up to 6TB capacity
eSATA N/A
Auxiliary Interface
USB ۲ USB 2.0
RS232 N/A
RS485 N/A
Electrical
Power Supply DC 12 V/2 A
Power Consumption

(Without HDD)

 < 10 W
Construction
Dimensions Compact 1U, 260 mm × ۲۳۶ mm × ۴۸ mm (10.2″ × ۹.۳″ × ۱.۹″)
Net Weight

(without HDD)

 ۰.۸۶ kg (1.90 lb)
Gross Weight ۱ kg (2.2 lb)
Installation Desktop installation
Environmental
Operating Conditions –۱۰ °C ~ +45 °C (+14 °F ~ +113 °F), 10~ 90% RH
Storage Conditions –۲۰ °C ~ +70 °C (–۴ °F ~ +158 °F) , 0~ 90% RH
Third-party Support
Third-party Support Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Certifications
Certifications FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
UL: UL 60950-1

دانلود

بروشور (Datasheet):

راهنما:

سیستم عامل (Firmware):
