دستگاه ضبط دیجیتال سری کوپر داهوا مدل XVR1B04/08

XVR1B04/08

4/8 Channel Penta-brid 1080N/720P Cooper 1U Digital Video Recorder

  • H.265+/H.265 dual-stream video compression
  • Supports HDCVI/AHD/TVI/CVBS/IP video inputs
  • Max 5/10 channels IP camera inputs, each channel up to 2MP/6MP; Max 20/40Mbps Incoming Bandwidth
  • Long transmission distance over coax cable
  • Supports 1 SATA HDD, up to 6TB

مقایسه
دسته: ,

مشخصات سایت منبع

System
Main Processor Embedded Processor
Operating System Embedded LINUX
Video and Audio
Analog Camera Input ۴/۸ Channel, BNC
HDCVI Camera ۴CH: 1080P@25/30fps, 720P@50/60fps, 720P@25/30fps

۸CH: 1080P@25/30fps, 720P@25/30fps
AHD Camera ۱۰۸۰P@25/30, 720P@25/30fps
TVI Camera ۱۰۸۰P@25/30, 720P@25/30fps
CVBS Camera PAL/NTSC
IP Camera Input ۴CH: 4+1, each channel up to 2MP

۸CH: 8+2, each channel up to 6MP
Audio In/Out ۱/۱, RCA
Two-way Talk Reuse audio in/out, RCA
Recording
Video Compression H.265+/H.265/H.264+/H.264
Resolution ۱۰۸۰N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Record Rate Main Stream:

۴CH: All channels 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)

۸CH: the 1st channel 1080N/720P(1~25/30fps), others ۱۰۸۰N/720P(1~15fps); 960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)

Sub stream:

۴CH: CIF/QCIF (1~15fps)

۸CH: CIF/QCIF (1~7fps)
Video Bit Rate ۳۲Kbps ~ 4096Kbps Per Channel
Record Mode Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval ۱ ~ ۶۰ min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Audio Compression G.711A, G.711U, PCM
Audio Sample Rate ۸KHz, 16 bit Per Channel
Audio Bit Rate ۶۴Kbps Per Channel
Display
Interface ۱ HDMI ,1 VGA
Resolution ۱۹۲۰×۱۰۸۰, ۱۲۸۰×۱۰۲۴, ۱۲۸۰×۷۲۰
Multi-screen Display When IP extension mode not enabled:

۴CH: 1/4

۸CH: 1/4/8/9

When IP extension mode enabled:

۴CH: 1/4/6

۸CH: 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Network
Interface ۱ RJ-45 Port (100M)
Network Function HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Max. User Access ۱۲۸ users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 16.12, CGI Conformant
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × ۱۸), Video Loss, Tampering and Diagnosis
Alarm input N/A
Relay Output N/A
Playback and Backup
Playback ۴CH: 1/4

۸CH: 1/4/9
Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/Network
Storage
Internal HDD ۱ SATA Port, up to 6TB capacity
eSATA N/A
Auxiliary Interface
USB ۲ USB 2.0
RS232 N/A
RS485 N/A
Electrical
Power Supply DC12V/1.5A
Power Consumption

(Without HDD)

 <10W
Construction
Dimensions Cooper 1U, 197mm×۱۹۲mm×۴۱mm (7.8“×۷.۶”×۱.۶“)
Net Weight

(without HDD)

 ۰.۵۴kg (1.19lb)

۰.۵۶kg (1.23lb)
Gross Weight ۰.۹۳kg (2.05lb)
Installation Desktop installation
Environmental
Operating Conditions -۱۰°C ~ +45°C (+14°F ~ +113°F), 10~ 90% RH
Storage Conditions -۲۰°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH
Third-party Support
Third-party Support Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Certifications
Certifications FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1

CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
UL: UL 60950-1
