دستگاه ضبط تصاویر داهوا HCVR8816S-S3Environmental | ||
| Operating Conditions | -۱۰°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa | |
| System | ||
| Main Processor | Embedded Processor | |
| Operating System | Embedded LINUX | |
Video Detection and Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips | |
| Video Detection | Motion Detection, MD Zones: 396 (22 × ۱۸), Video Loss and Camera Blank | |
| Alarm input | ۱۶ | |
| Relay Output | ۶ | |
| Tracking Trigger Event | N/A | |
Display | ||
| Interface | ۲ HDMI ,1 VGA,1 TV | |
| OSDدستگاه ضبط تصاویر داهوا HCVR8816S-S3 | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
Recording | ||
| Compression | H.264+/H.264 | |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop | |
| Record Interval | ۱ ~ ۶۰ min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec | |
Playback and Backup | ||
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) | |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom | |
| Backup Mode | USB Device/Network/Internal SATA burner/eSATA Device | |
Third-party Support | ||
| Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more | |
Audio and Video | ||
| Audio In/Out | ۱۶/۱, BNC | |
Network | ||
| Network Function دستگاه ضبط تصاویر داهوا HCVR8816S-S3 | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS, etc.) | |
| Max. User Access | ۱۲۸ users | |
| Smart Phone | iPhone, iPad, Android | |
Electrical | ||
| Power Consumption | <40W (Without HDD) | |
Storage | ||
| HDD Mode | Single | |
| eSATA | ۱ Port | |
Auxiliary Interface | ||
| Front Cover | N/A | |
| USB | ۴ USB Ports (2 USB 2.0 , 2 USB 3.0) | |
| RS232 | ۱ port, For PC communication & Keyboard | |
| RS485 | ۱ Port, for PTZ Control | |
Construction | ||
| Gross Weight | ۹.۸kg (21.6lb) | |
| Installation | Desktop installation | |
